Ringlock Scaffolding

Short Description:

Ringlock scaffolding is a modular scaffold system which is more safe and convenient it can be divided into 48mm system and 60 system. Ringlock system is constitute of standard, ledger, diagonal brace, jack base, u head and other componets. Standard is welded by rosette with eight hole that four small holes to connect ledger and another four big holes to connect diagonal brace.


Product Detail

Product Details

Ringlock scaffolding is a modular scaffold system which is more safe and convenient it can be divided into 48mm system and 60 system. Ringlock system is constitute of standard, ledger, diagonal brace, jack base, u head and other componets. Standard is welded by rosette with eight hole that four small holes to connect ledger and another four big holes to connect diagonal brace.

Advantage5

Item

Length(mm)

Size(mm)

Size(mm)

Standard with spigot Q345

L=1000

φ48.3*3.25

φ60*3.25

L=1500

φ48.3*3.25

φ60*3.25

L=2000

φ48.3*3.25

φ60*3.25

L=2500

φ48.3*3.25

φ60*3.25

7

Item

Length(mm)

Size(mm)

Size(mm)

Ledger(Q235/Q345)

L=600

φ48.3*3.25

φ48.3*2.5

L=700

φ48.3*3.25

φ48.3*2.5

L=900

φ48.3*3.25

φ48.3*2.5

L=1200

φ48.3*3.25

φ48.3*2.5

L=1500

φ48.3*3.25

φ48.3*2.5

L=1800

φ48.3*3.25

φ48.3*2.5

L=2000

φ48.3*3.25

φ48.3*2.5

L=2500

φ48.3*3.25

φ48.3*2.5

13

Item

Length(mm)

Size (mm)

Size (mm)

 diagonal brace Q345/Q235

L=1500*900

φ48.3*2.5

φ42*2.5

L=1200*1200

φ48.3*2.5

φ42*2.5

L=1200*1500

φ48.3*2.5

φ42*2.5

L=1500*1500

φ48.3*2.5

φ42*2.5

L=1800*1500

φ48.3*2.5

φ42*2.5

L=2400*1500

φ48.3*2.5

φ42*2.5

2

Item

Length

Sizemm

Sizemm

Base collar Q345

L=300

φ59*4*100

φ70*4*110

φ48.3*3.2*200

φ60*3.2*200

31 Item Length(mm) Size(mm) Size (mm)
Screw Jack Foot L=600140*140*6mm φ38.5 φ48.5
 4 Item Length(mm) Size(mm) Size (mm)
ScrewJack Head L=600180*150*50*6mm φ38.5 φ48.5

Advantage

1. Advanced technology, reasonable joint design ,stable connection.

2. Assembling easily and quickly , greatly reduce the time and labor cost.

3.Uprade raw materials by low-alloy steel .

4.High zinc coating and long life to use, clean and beautiful.

5.Automatic welding ,high precision and superior quality.

6.Stable structure ,high bearing capacity, safe and durable.
